Electro-Voice ELX200-10 10″ passive loudspeaker

The Electro-Voice ELX200 series sets a new standard in performance, durability, and portability. Designed for real-world professional applications, these speakers combine high-output power, advanced transducer technology, and a rugged composite enclosure. With its precise sound delivery, easy transport, and robust build, the ELX200 is the ideal solution for demanding audio environments, offering top-tier sound quality and reliability.

SKU: ELX200-10 Category: Tag:

Product Overview:

The Electro-Voice ELX200 series is engineered to offer unmatched sound quality, portability, and durability at its price point. Featuring a 1200 W peak power output and a 127 dB peak SPL, the ELX200 is designed to withstand over 500 hours of abuse and endurance testing, far exceeding industry standards. With a 1.4-inch titanium compression driver and a custom EVS-10M woofer, this system delivers transparent high-frequency response and exceptional low-frequency reproduction. The patented Signal Synchronized Transducers (SST) waveguide ensures precise coverage, minimal distortion, and maximum acoustical loading, making the ELX200 an ideal choice for professional applications.

Product Features:

  • 1200 W Peak Power & 127 dB SPL: Powerful output with industry-leading reliability, verified through 500+ hours of abuse and endurance testing.
  • Titanium Compression Driver: 1.4-inch DH-1L driver for clear, extended high-frequency response.
  • Custom EVS-10M Woofer: Designed for superior durability and exceptional low-frequency reproduction.
  • Signal Synchronized Transducers (SST): EV-patented design for precise coverage, minimal distortion, and optimized acoustical performance.
  • Professional-Grade Hardware: Includes M10 threaded mounting points, integrated pole-mounts, and a durable two-handle design for easy transport.

Specifications

Suspension (3) M10 suspension points
Minimum Impedance 7.2Ω
HF Transducer DH-1L 1-inch titanium compression driver
Speaker Type Full-Range
Woofer Size 10inch
Powered or Passive Passive
Frequency Response (-3 dB)¹ 65 Hz – 20 kHz
Frequency Range (-10 dB)¹ 49 Hz – 22 kHz
Max. SPL/1m (calc)² 127dB
Coverage (Nominal -6 dB) H 90°
Coverage (Nominal -6 dB) V 60°
LF Transducer EVS-10M 254 mm (10 in)
Power Rating 1200W
Crossover Frequency 2 kHz
Connector Type Dual NL4
Enclosure Material Polypropylene Composite
Grille 18 AWG steel with powdercoat
Available Color Black or White
Height 20.91″ (531mm)
Recommended High-Pass Frequency 55Hz
Width 12.99″ (330mm)
Depth 12.56″ (319mm)
Weight Net 29.54lbs (13.4kg)
Shipping Weight 33.73lbs (15.3kg)
Family ELX200
Nominal Impedance 8Ω
Axial Sensitivity (SPL, 1 W @ 1 m) 90dB
Power Handling (Continuous / Peak) 300 W/1200W
