Ahuja TZA-1200 Mixer Amplifier

Ahuja TZA-1200 Overview

The Ahuja TZA-1200 is a versatile 120-watt, 2-zone PA mixer amplifier, designed for smaller installations such as places of worship. It offers the flexibility to connect both external and internal speakers with independent sound level settings, making it perfect for environments that require different audio zones. It supports both AC and DC operation and includes a variety of features to ensure optimal sound control and flexibility.

Product Features

1. 5 Mic & 2 Aux Inputs
   Multiple input options provide the flexibility to connect microphones and auxiliary devices for a variety of audio sources.
2. 60W+60W Power Output
   Offers 60W per zone, ideal for small to medium-sized installations, ensuring clear sound across two zones.
3. Dual Speaker Groups
   Allows for the connection of two separate groups of speakers, making it ideal for multi-zone audio setups.
4. Preamplifier Output
   Facilitates connection to external amplification or recording equipment, extending the system’s capabilities.
5. Bass and Treble Controls
   Customize the sound quality with bass and treble adjustments for fine-tuning audio output to suit the environment.
6. Zone On/Off Facility
   Provides control over each zone independently, enabling different audio levels for external and internal speakers.
7. AC/DC Operation
   Flexible power options for both AC (220-240V) and DC (12V Car Battery) operation, ensuring continued use during power outages.
8. Compact Design
   A compact, easy-to-install unit that is well-suited for smaller spaces, such as places of worship, schools, or small retail areas.

Specifications

• Power Output:
  • 90W + 90W Max.
  • 60W + 60W RMS at 10% THD
  • 55W + 55W RMS at 5% THD
  • 50W + 50W RMS at 2% THD
• Input Channels:
  • 5 × Mic (0.6mV/4.7kΩ)
  • 1 × Aux (100mV/470 kΩ)
  • 1 × Aux (200mV/250kΩ, RCA Jack)
• Frequency Response: 70-15,000Hz ±3dB
• Signal-to-Noise Ratio: 60dB
• Power Supply:
  • AC: 220-240V 50/60Hz
  • DC: 12V (12V Car Battery)
• Power Consumption:
  • AC: 250VA
  • DC: 5A
• Dimensions: 400 × 130 × 290 mm
• Weight: 10.1 Kg
